Iterator Design Pattern (Great on your favorite looping)

Iterator Design Pattern is one of the patterns that use in collections to traversal the objects(Looping). Iterator Design Pattern provides the way to access and traversal item sequentially without exposing their underlying representation.

Every programming language has data structures to keep store groups of objects. The main Objective of the Iterator Design Pattern is to access the collection of objects without exposing the internal structure.

Consider there is a collection of objects in a structure(Ex: In Java Collections) and clients want to iterate or traverse between the objects. In those situations, the ideal way is to use an iterator to find the object or loop the whole collection.

There are four participants in Iterator Design Pattern. Those are

• Iterator Interface: Define the methods to traverse between objects
• Concrete Iterator class: Implementation of methods in an interface. This will provide a way to store objects and get the state of each.
• Aggregate Interface: Collection class which defines iterator for client
• Concrete Aggregate Class: Return a real iterator for external use by implementing an aggregate interface.

Client class is an iterating loop of objects. That means patterns help clients loop their objects.

Let’s take a real-world simple example to iterate objects using an iterator design pattern.

Iterator Design Pattern Real World Example

Consider in Hospital OPD or in channel centers, there are patients waiting in a queue according to the appointments. A doctor gives treatments to patients, but the hospital provides a way to sequence the patients according to appointment number. Once a doctor arrives, then loop the patient’s queue by hospital nurses just like an iterator.

In this scenario, doctors expose patients to investigate their health. But the hospital plans patients in a sequential manner. Let’s move into a class diagram of this scenario and then move into the implementation.

Iterator Design Pattern in Java

Let’s implement the above diagram. The client iterates patients sequentially.

// Main object use to create seaquence
class Patients
{
    private String name;
    private String appoinmentNo;

   public Patients(String name, String appoinmentNo) {
      this.name = name;
      this.appoinmentNo = appoinmentNo;
   }
    public String getName() {
        return name;
    }
    public String getAppoinmentNo() {
        return appoinmentNo;
    }
}

//Definition of iterator behaviours
interface Iterator<E>
{
 // To get the next element(Patient )
    E next();
 // To retrieve the current element (Patient )
    E currentItem();
 // To check whether there is any next element (Patient ) or not.
    boolean hasNext();
}

// Implements the Iterator with common behaviours
class PatientIterator implements Iterator<Patients> {

    private Patients[] patients;
    private int position;

    public PatientIterator(Patients[] patients)
   {
      this.patients = patients;
      position = 0;
   }
   @Override
   public Patients next() {
      return patients[position++];
   }
   @Override
   public Patients currentItem() {
      return patients[position];
   }
   @Override
   public boolean hasNext() {
     if(position >= patients.length)
        return false;
     return true;
    }
}

//Define the iterator fro client
interface List<E>
{
    Iterator<E> iterator();
}

// Create Patient iterator by implementing iterator
class PatientList implements List<Patients>
{
    private Patients[] patients;

    public PatientList(Patients[] patients)
    {
        this.patients = patients;
    }

    @Override
    public Iterator<Patients> iterator() {
        return new PatientIterator(patients);
    }
}

// Client class use the iterator
public class IteraterPatientDemo {
   public static void main(String[] args){
      Patients[] ps = new Patients[4];
      ps[0] = new Patients("John","01");
      ps[1] = new Patients("Kain","02");
      ps[2] = new Patients("Dan","03");
      ps[3] = new Patients("Ann","04");
      List<Patients> list = new PatientList(ps);
      Iterator<Patients> iterator = list.iterator();

      while(iterator.hasNext()) {
         Patients currentPatient = iterator.next();
         System.out.println("Appoinment No: "+currentPatient.getAppoinmentNo() +" is "+currentPatient.getName());
      }
   }
}

Output

Appoinment No: 01 is John
Appoinment No: 02 is Kain
Appoinment No: 03 is Dan
Appoinment No: 04 is Ann

Advantages of Iterator Design Pattern

• Traversal with a list of objects without affecting loop objects.
• Easy to create different types of iterators by extending (Inheritance).
• Do not need to know the size of the list.

Iterator Pattern Usage

As you know this is for returning a list of item/s as a sequence and recognizable by behavioral methods sequentially returning instances of a different type from a queue. Patterns heavily used for reverse through the list and supported by Java using the below packages.
