Command Design Pattern (Order Now)

Command Design Pattern is to decouple an action from its action invoker. This is achieved by introducing a new Command layer between the action and the invoker. Action creates inside the receiver and there can be multiple actions in a single receiver class. Invoker is invoking a single function by calling a new command layer without knowing receiver actions.

In Above “Invoker is invoking single function” means Invoker is executing a command. Once the invoker executes the command then the command executes the appropriate action inside the receiver. Invoker invokes command without knowing details of receiver’s action. it just executes the command and the middle command execute the appropriate actions.

Command Design Pattern comes under behavioral patterns(Design Pattern) and encapsulated information about actions. That means changes done to the receiver’s actions do not affect with invoker. It’s because of command layer decouples the invoker and action.

There are three main components in Command Design Pattern, but a command (interface/Abstract class) has concrete implementations. Those components are,

• Receiver: Which is executing some real actions.
• Command interface/abstract class: Declaring command to execute an action in Receiver
• Concrete command Implementations: Implementation of Command interface/abstract class which is perform the Receiver’s action by keeping reference with the Receiver
• Invoker: just invoke the command to perform some work.

Let’s move into an Example of how these components map with Real World objects.

Command Design Pattern Real World Example

Let’s take a simple example of a color light system handling traffic in a junction. There is a traffic control center that gives commands according to the traffic. Panel colors change when according to the given command. The Control center just gives commands without knowing color patterns, but the middle command executes the correct action. As a result, colors are visible accordingly.

In this case, the traffic control center is the invoker, and Color panel lights are the receivers. Processing and executing the command by command layer which encapsulates data between light actions and traffic control center.

There are three colors in the panel Red, yellow, and green. The traffic control center gives four types of commands to invoke one at a time. Consider those commands Go, Stop, Ready to go, and Ready to stop. Let’s move on to the class diagram.

Command Design Pattern in Java

Class diagram design showing four implementations of commands, three colors, and a traffic control invoker. Let’s move into the implementation of the class diagram.

//First create Receiver classes
//GreenLight class Includes Green light related functinalies(turnOn/turnOff)
class GreenLight{
   public  void turnOn() {
        System.out.println("Showing Green Light");
    }
    public void turnOff() {
        System.out.println("Hiding Green Light");
    }
}

//YellowLight class Includes Yellow light related functinalies(turnOn/turnOff)
class YellowLight{
   public  void turnOn() {
        System.out.println("Showing Yellow Light");
    }
    public void turnOff() {
        System.out.println("Hiding Yellow Light");
    }
}

//RedLight class Includes Red light related functinalies(turnOn/turnOff)
class RedLight{
   public  void turnOn() {
        System.out.println("Showing Red Light");
    }
    public void turnOff() {
        System.out.println("Hiding Red Light");
    }
}

// Then create Command interface with execute command
abstract class Command {
   protected YellowLight yellowLight;
   protected RedLight redLight;
   protected GreenLight greenLight;
   public Command(YellowLight yellowLight, RedLight redLight, GreenLight greenLight) {
      this.yellowLight = yellowLight;
      this.redLight = redLight;
      this.greenLight = greenLight;
   }
   abstract void execute();
}

// There are four Concrete commands class
class GoCommand extends Command {
   public GoCommand(
           YellowLight yellowLight,RedLight redLight,GreenLight greenLight) {
      super(yellowLight ,redLight,greenLight);
   }
   @Override
   public void execute() {
      greenLight.turnOn();
      redLight.turnOff();
      yellowLight.turnOff();
   }
}
class StopCommand extends Command {
    public StopCommand(
            YellowLight yellowLight,RedLight redLight,GreenLight greenLight) {
      super(yellowLight ,redLight,greenLight);
   }
    @Override
     public void execute() {
        redLight.turnOn();
        yellowLight.turnOff();
        greenLight.turnOff();
    }
}
class ReadyToStopCommand extends Command {
    public ReadyToStopCommand(
               YellowLight yellowLight,RedLight redLight,GreenLight greenLight) {
      super(yellowLight ,redLight,greenLight);
   }
     public void execute() {
        yellowLight.turnOn();
        redLight.turnOff();
        greenLight.turnOff();
    }
}
class ReadyToGoCommand extends Command {
    public ReadyToGoCommand(
              YellowLight yellowLight,RedLight redLight,GreenLight greenLight) {
      super(yellowLight ,redLight,greenLight);
   }
     public void execute() {
        yellowLight.turnOn();
        redLight.turnOn();
        greenLight.turnOff();
    }
}

class TrafficControlCenter {
    Command command;
     //Setting runtime command
    public void setCommand(Command command) {
        this.command = command;
    }
     //Invoke appropriate command
    public void executeCommand() {
        command.execute();
    }
}

public class TrafficControlCommandClient {
   public static void main(String[] args) {
      GreenLight greenLight = new GreenLight();    //receiver 1 Green Light
      RedLight redLight = new RedLight();  //receiver 2 Red Light
      YellowLight yellowLight = new YellowLight();   //receiver 3 Yellow Light
      TrafficControlCenter controlCenter=new TrafficControlCenter(); //Invoker
      System.out.println("Stop Command");
      controlCenter.setCommand(
                    new StopCommand( yellowLight ,redLight,greenLight ));
      controlCenter.executeCommand();
      System.out.println("");
      System.out.println("Ready To Go Command ");
      controlCenter.setCommand(
                     new ReadyToGoCommand( yellowLight ,redLight,greenLight));
      controlCenter.executeCommand();
      System.out.println("");
      System.out.println("Go Command");
      controlCenter.setCommand(
                    new GoCommand( yellowLight ,redLight,greenLight ));
      controlCenter.executeCommand();
      System.out.println("");
      System.out.println("Ready To Stop Command");
      controlCenter.setCommand(
                    new ReadyToStopCommand( yellowLight ,redLight,greenLight ));
      controlCenter.executeCommand();

   }
}

Output

Stop Command
Showing Red Light
Hiding Yellow Light
Hiding Green Light

Ready To Go Command
Showing Yellow Light
Showing Red Light
Hiding Green Light

Go Command
Showing Green Light
Hiding Red Light
Hiding Yellow Light

Ready To Stop Command
Showing Yellow Light
Hiding Red Light
Hiding Green Light

According to the Command Design Pattern traffic control system is implemented and this is not the real way of handling traffic control, but this is just a demonstration of traffic control.

There are four commands and commands executing the color lights correctly.

Advantages of Command Design Pattern

• It’s easy to extend by adding commands or receivers without affecting existing code and functionality. Consider the need to add a Blink Yellow Color Option. It’s easy to add a new command.
• Hide the implementation from clients
• Separate(decouple) Receive and invoker make code more maintainable

Once following the Command Design Pattern there needs to create many classes to achieve the problems that may disadvantage.
